Dual DC Motor Driver for AGV & Robotics | 1500W Brushless/Brushed Hybrid Controller

This Dual-Channel DC Motor Driver is a hybrid controller engineered for AGV (Automated Guided Vehicle) and robotic systems, enabling simultaneous control of two DC motors (brushed or brushless). It integrates closed-loop speed & angle control, supports 1 drive + 2 motor topology, and simplifies wiring/control architecture for space-constrained applications. With multi-protocol communication (RS232/RS485/CAN/IO) and extensive sensor compatibility, it delivers high-current, reliable performance for AGVs, collaborative robots (ARM), and mobile platforms.

Functions & Features

Dual Motor Control: Simultaneously drives 2 DC brushed or brushless motors (mixed types supported).
Topology Optimization: Adopts 1-drive-2-motor design to save installation space and simplify control logic.
Closed-Loop Precision: Auto-zeroing, integrated speed闭环 (closed-loop) + angle闭环 (closed-loop) control for accurate motion.
Multi-Feedback Support: Works with incremental/absolute encoders, Hall sensors, potentiometers, and tachogenerators.
Flexible Communication: RS232, RS485, CAN BUS, and IO analog control for seamless system integration.
Easy Configuration: Micro USB port for software setup + visual debugging interface.
Sensor Compatibility: Interfaces with magnetic navigation, RFID, and laser obstacle sensors.
Safety & Protection: Over-voltage, under-voltage, short-circuit, over-current, and reverse-polarity protection.
Reliability: 2-year warranty (non-human damage) for worry-free deployment.

Technical Parameters

Parameter	Specification
Model	CNS-MI50HB Series
Rated Voltage	18–60V DC (configurable to motor specs)
Rated Current	Dual-channel: 50A/ch (peak 100A, 2s)
Motor Type Support	DC brushed / brushless (mixed control)
Communication Interfaces	RS232-HS, RS485-modbus, CAN-HS (CANopen), IO analog
Feedback Support	Incremental/absolute encoder, Hall, potentiometer, tachogenerator
Control Modes	Speed闭环, Angle闭环, Open-loop
Protection	Over-voltage, under-voltage, short-circuit, over-current, reverse polarity
Installation Space	Saves space (1-drive-2-motor topology)
Certification	CE, RoHS (compliant)
Warranty	2 years (non-human damage)
