Wireless Optical Data Transmitter | 100Mbps Ethernet Bridge for AGV & Industrial IoT

This Wireless Optical Data Transmission Device utilizes visible or invisible light as an information carrier for high-speed, license-free data communication. It is designed to replace traditional fiber optics and network cables, offering a cost-effective and flexible solution for industrial environments where wired connections are impractical due to obstacles, moving parts, or complex layouts.

Product Introduction

This Wireless optical Data Transmission Device utilizes visible or invisible light as an information carrier for high-speed, license-free data communication. It is designed to replace traditional fiber optics and network cables, offering a cost-effective and flexible solution for industrial environments where wired connections are impractical due to obstacles, moving parts, or complex layouts.

The device features ultra-high transmission speeds of up to 100Mbit/s (Full-Duplex) and supports standard Industrial Ethernet protocols (such as Profinet and EtherCAT) without protocol restrictions. With configurable transmission distances ranging from 2m to 30m and rapid link establishment (under 2.5s), it ensures low-latency and highly reliable communication, making it ideal for AGVs, intelligent storage, and automated production lines.

Key Features & Functions

Ultra-High Speed: Supports bandwidths up to 100Mbit/s with Full-Duplex communication.
Long Transmission Range: Available in models with ranges of 2m, 5m, 10m, and 30m.
Industrial Protocol Support: Transparent transmission supporting mainstream industrial buses (Profinet, EtherCAT, etc.).
Rapid Connection: Initial link setup time < 2.5 seconds; Reconnection time < 50ms.
Safe & Reliable: Utilizes laser technology with high security and interference resistance.
Wide Application: Perfect for logistics warehouses, automated guided vehicles (AGVs), hoisting equipment, military, and aerospace applications.
Wavelength Options: Features 780nm and 850nm source wavelengths (devices must use complementary wavelengths for pairing).

Technical Parameters

Parameter	Specification
Model Series	OPS Series
Transmission Distance	2m / 5m / 10m / 30m (Optional)
Data Rate	100Mbit/s (Ethernet)
Interface	Ethernet (No protocol restrictions)
Light Source	Laser
Wavelength	780nm / 850nm (Optional, must differ between paired units)
发散角度 (Divergence Angle)	±1°
Initial Link Time	< 2.5s
Re-link Time	< 50ms
Supply Voltage	DC 10V - 30V (Standard: EN 60825-1:2007)
Power Consumption	< 800mW
Operating Temperature	-10°C ~ +65°C
Storage Temperature	-10°C ~ +60°C
Humidity	85% RH (Non-condensing)
Ingress Protection	IP65
Material	Aluminum Alloy
