This is a plug-and-play multifunctional data collection device that integrates a Bluetooth ID card reader, 1D/2D barcode scanner, and low-frequency tag reader. Operating at both 125 kHz and 13.56 MHz frequencies, it is compatible with a wide range of ID/IC cards (such as TK4100, EM4100, S50, S70) and can scan various barcodes and on-screen codes. Utilizing Bluetooth HID keyboard emulation, it transmits scanned data directly to text fields on Android, iOS, Windows, and other Bluetooth-enabled devices without requiring any drivers or secondary development. Its compact, portable design, long battery life, and versatile connectivity make it an ideal tool for mobile data entry, asset tracking, attendance systems, and access control.
The HX-R58D is a dedicated 125 kHz low-frequency contactless RFID Card reader that integrates wireless RFID technology with Bluetooth communication. It adopts a keyboard emulation mode via Bluetooth, requiring no secondary development and enabling true plug-and-play operation. The reader can directly input swiped ID card data (card number) into text fields on Android and iOS smartphones, tablets, and desktop computers. It supports multiple data output formats, with 8‑digit hexadecimal as the default, and allows customization of the output data format.
In addition to its plug‑and‑play convenience, the HX‑R58D is highly energy‑efficient, offering a standby time of up to 3 years. It eliminates traditional wired data transfer methods and does not require an external power source, as it is equipped with a built‑in lithium battery. Once the Bluetooth on the receiving device is successfully paired with the reader, the UID of RFID cards can be transmitted directly to the receiving device via Bluetooth.
All-in-One Functionality: Combines low-frequency (125 kHz) ID card reading, 13.56 MHz high-frequency IC/NFC card reading, and 1D/2D barcode scanning in one handheld device.
True Plug & Play: Emulates a Bluetooth keyboard (HID proFile). Once paired, card or barcode data is instantly sent to any active text field, eliminating the need for custom apps.
Dual Frequency & Broad Compatibility: Supports major low-frequency (TK4100, EM4100) and high-frequency (MIFARE S50/S70, Ultralight, CPU) card protocols for maximum flexibility.
Wireless & Long-Range: Features stable Bluetooth/2.4G wireless communication with an effective range of up to 10 meters.
Long Battery Life: Equipped with a 1000mAh rechargeable battery supporting extended standby time for all-day use.
Multi-Platform Support: Compatible with iOS, Android, Windows (XP/7/10/11), and Linux systems.
User-Friendly Design: Simple one-button pairing, clear multi-color LED status indicators, and audible feedback.
Parameter | Details |
|---|---|
Models | R58B, R58C, R58D (HX-R58D for 125 kHz ID focus) |
Core Functions | ID/IC/RFID card Reader, 1D/2D & On-Screen Barcode Scanner |
Supported Frequencies | 125 kHz, 13.56 MHz (model dependent) |
Supported Cards | 125 kHz: TK4100, EM4100, etc. / 13.56 MHz: MIFARE S50, S70, Ultralight, CPU, etc. |
Barcode Support | 1D Barcodes, 2D QR Codes, On-Screen Codes |
Wireless Connectivity | Bluetooth (HID Profile), 2.4G Wireless |
Read Distance (Card) | 20 mm - 60 mm (card-dependent) |
Read Speed | < 0.1 seconds |
Data Rate | 106 Kbps |
Default Output | 8-digit Hex (configurable to Decimal, etc. via software) |
Battery | 1000mAh Li-ion, 5V Micro-USB Charging |
Operating Temperature | -20°C to +70°C |
Operating Current | 100 mA |
Dimensions (Device) | ~105 x 48 x 25 mm (varies slightly by model) |
Weight (Device) | ~50 g |
OS Support | iOS, Android, Windows XP/7/10/11, Linux |
