4G/5G USIM Card Reader Writer & SIM Programmer | Multi-OS Support (Ubuntu, Windows, Mac)

This versatile USIM Card Reader/Writer is a professional, all-in-one solution for 4G/5G SIM card activation, programming, and general-purpose smart card management. Designed for telecom operators, service centers, and developers, it seamlessly handles USIM card personalization for 4G/5G networks, standard SIM card programming, and read/write operations on a wide range of contact-based smart cards (CPU, memory, and logical encryption cards). Featuring a compact, ergonomic design and broad multi-platform support—including Windows, Linux (Ubuntu), and macOS—this device offers high-speed data transfer (up to 600kbps), plug-and-play convenience via CCID, and robust SDK support for custom application development. It is the essential tool for SIM provisioning, testing, and secure identification tasks.

Shop

Technical Parameters & Specifications

Model: Multi-Platform USIM/Smart Card Reader-Writer
Primary Functions: 4G/5G USIM card activation (bootstrap), SIM card programming (burning), and general contact smart card read/write.
Card Interface & Compatibility:

Slots: 1 x Standard ID-1 (ISO 7816) slot + 1 x SIM card slot (integrated), eliminating the need for adapters.
Supported Cards: 4G/5G USIM cards, standard SIM cards, ISO 7816 A/B/C class contact smart cards (CPU cards), memory cards (including proprietary SCM Library support), and logical encryption cards.
Protocols: Supports T=0 and T=1 communication protocols.
Durability: Card slot rated for 100,000 insertion cycles (friction type).

Performance:

Read/Write Speed: Up to 600 kbps (supports PPS negotiation for optimal speed).
Clock Speed: Up to 5 MHz, with an operational speed of up to 12 MHz.

Host Connection & Software:

Interface: USB 2.0 (12 Mbps), bus-powered. Includes a 1.5-meter USB cable.
Driver: Plug-and-play via standard USB CCID and PC/SC drivers.
OS Support: Windows (XP to 11, Server), Linux (including Ubuntu, kernel 2.4.x/2.6.x, 32/64-bit), macOS, Solaris, Android. Also supports domestic operating systems.
Development: Supports secondary development with a free, comprehensive SDK and technical support.

Physical Specifications:

Dimensions: Approximately 68mm (L) x 48mm (W) x 15mm (H).
Weight: 70g.
Indicator: LED status light.

Functional Description

Telecom-Focused SIM Management: Specifically engineered for the telecommunications industry, enabling efficient activation (bootstrap), programming, and testing of 4G and 5G USIM cards at operator retail Stores, service centers, and for testing procedures.
Dual-Slot Universal Card Handling: The integrated SIM slot and standard ID-1 slot allow direct operation on two common card form factors without converters, supporting USIMs, SIMs, national eIDs (EID chips), bank cards, and various memory cards.
High-Speed & Reliable Performance: Delivers fast data transfer rates up to 600 kbps, crucial for batch card personalization and data-intensive applications, backed by a durable 100,000-cycle card connector.
Cross-Platform Plug-and-Play Compatibility: Achieves true out-of-the-box functionality on a vast range of operating systems—from Windows PCs and Ubuntu Linux machines to macOS systems—via universal CCID/PC/SC standards, ensuring easy deployment in any IT environment.
Developer & Integrator Ready: Offers a free SDK and technical support, empowering system integrators and software developers to create custom solutions for card issuance, security authentication, and data management tailored to specific business needs.
