Z100-R Dual Interface Card Reader | USB Magnetic Stripe & RFID Reader/Writer for POS & Kiosks

The Z100-R is a professional-grade, multi-functional smart card reader terminal designed for seamless integration into modern point-of-sale (POS), self-service kiosk, and access control systems. It combines magnetic stripe reading and contactless RFID (13.56MHz) IC card read/write capabilities into a single, compact, and plug-and-play USB device. Engineered for reliability and developer-friendly operation, it is ideal for applications in attendance tracking, payment processing, membership management, vending, and secure access. Its robust construction, compliance with international standards, and extensive software support make it a versatile solution for system integrators and businesses worldwide.

Shop

Key Parameters / Specifications

Model: Z100-R
Interface: USB 2.0, USB-OTG (for Android 3.1+)
Magnetic Card Reading:

Tracks: Supports 1, 2, or all 3 tracks, selectable.
Direction: Bidirectional swipe.
Head Life: Approximately 500,000 swipes.
Standards: Compatible with ISO 7811, AAMVA, CADMV.

RFID (Contactless IC Card) Function:

Frequency: 13.56 MHz
Read/Write Distance: 0 - 5 cm (Supports MIFARE One at ~1.5cm)
Supported Card Types: ISO 14443A, MIFARE One S50/S70, MIFARE Mini, MIFARE Ultralight, DESFire, MIFARE Plus.

General Specifications:

Power Supply: USB bus-powered (45~65mA).
Indicators: Dual LED (Power/Status) & Buzzer for auditory feedback.
Security: Built-in Triple DES encryption option.
Dimensions: 100mm (L) x 34mm (W) x 30mm (H).
Weight: 90g.
Material: ABS Plastic.
Color: Black.
Operating Temperature: -20°C to 55°C.
Certifications: CE, FCC, RoHS.
OS Support: Windows (7, 10, 11, Server), Linux, Android.

Functional Description

Dual-Function Card Processing: Serves as both a magnetic stripe reader and a contactless RFID Reader/writer, eliminating the need for separate devices.
True Plug-and-Play: USB interface requires no external power or additional drivers for major operating systems, ensuring quick and easy installation.
Robust & Developer-Friendly: Provides comprehensive software development kits (SDK) including DLLs, detailed documentation, and sample source code for multiple programming languages (C#, C++, Delphi, Java, VB.NET, PowerBuilder, etc.) to facilitate custom integration and secondary development.
User Feedback System: Features a programmable buzzer and a green LED to provide clear audible and visual confirmation of successful card reads.
Self-Diagnostic: Performs a self-check upon power-up for operational reliability.
Versatile Application: Perfect for enhancing advertising kiosks, self-service terminals, retail POS systems, Access Control units, and any smart card management system requiring secure identification or transaction processing.
